EM341
Rev 1.0
77
8.3.5. Registers
Note: Substitute “1” or “2” for “x” in the following detailed descriptions.
SC1_DATA: Address: 0x4000C83C Reset: 0x0
SC2_DATA: Address: 0x4000C03C Reset: 0x0
Register 8.5. SCx_DATA
SC1_DATA: Serial Data Register
SC2_DATA: Serial Data Register
Bit
31
30
29
28
27
26
25
24
Name
0
0
0
0
0
0
0
0
Bit
23
22
21
20
19
18
17
16
Name
0
0
0
0
0
0
0
0
Bit
15
14
13
12
11
10
9
8
Name
0
0
0
0
0
0
0
0
Bit
7
6
5
4
3
2
1
0
Name
SC_DATA
Bitname
Bitfield
Access
Description
SC_DATA
[7:0]
RW
Transmit and receive data register. Writing to this register adds a byte to the
transmit FIFO. Reading from this register takes the next byte from the
receive FIFO and clears the overrun error bit if it was set.
In UART mode (SC1 only), reading from this register loads the UART status
register with the parity and frame error status of the next byte in the FIFO,
and clears these bits if the FIFO is now empty.
