EM358x

Rev 1.0

Table 2.1. Bill of Materials for Figure 2.1

Item Qty Reference

Description

Manufacturer

ANT1

ANTENNA, <not specified>

BLN1

BALUN, CHIP MULTILAYER CERAMIC, 2.4

GHZ. 50/100 OHM, -40C TO 85C, 0805

Wurth 748421245

Johanson 2450BL15B100E

Murata LDB212G4010C-001

TDK HHM1520

CAPACITOR, <not specified>

CAPACITOR, <not specified>

CAPACITOR, 2.2 µF, 10 V, X5R, 10%, 0603

CAPACITOR, 1 µF, 6.3 V, X5R, 10%, 0402

CAPACITOR, 33 pF, ±5%, 50 V, NPO, 0402

C6, C10, C11

CAPACITOR, 22 pF, ±5%, 50 V, NPO, 0402

C7, C9

CAPACITOR, 1 pF, ±0.25 pF, 50 V, 0402, NPO

CAPACITOR, 1.8pF, ±0.25 pF, 50 V, 0402, NPO

FB1

FERRITE BEAD, 60 OHM, 500MA, 0603

Murata BLM18PG600SN1

CONNECTOR, USB, END LAUNCH, THROUGH

HOLE

Molex 67068-8110

CONNECTOR, HEADER, SHROUDED, 10

POSITION, DUAL ROW, VERTICAL, 0.050"

Samtec FTSH-105-01-L-DV-K

L1, L2, L3, L4

INDUCTOR, <not specified>

L5, L6

INDUCTOR, 2.7 nH, ±0.3 nH, 0402, MULTI-

LAYER

Murata LQG15HS2N7

RESISTOR, 15K OHM, 5%, 1/10W, 0402

RESISTOR, 10K OHM, 5%, 1/16W, 0402

RESISTOR, 1 OHM, 5%, 1/16W, 0402

RESISTOR, 1.5K OHM, 1%, 1/16W, 0402

R5, R6

RESISTOR, 26.1 OHM, 1%, 1/10W, 0402

RESISTOR, 10 OHM, 5%, 1/16W, 0402

R8, R9, R10, R11

RESISTOR, 100K OHM, 5%, 1/16W, 0402

MOSFET, 2N7002, 300MA, 830MW, 60V, TO-

236-3, SC-59, SOT-23-3

NXP Semiconductor 2N7002

IC, VOLTAGE REGULATOR, <not specified>

EM358x, ZIGBEE/802.15.4 RF

TRANSCEIVER, ARM CORTEX-M3, 32 or 64 kB

RAM, 256 or 512 kB FLASH, 48-QFN

EM3581-RTR/EM3582-RTR/

EM3585-RTR/



EM3586-RTR/EM3587-RTR/

EM3588-RTR
