EM358x

Rev 1.0

PA7

I/O

High

current

Digital I/O

Disable REG_EN with GPIO_DBGCFG[4]

TIM1C4

Timer 1 Channel 4 output

Enable timer output with TIM1_CCER

Select alternate output function with GPIO_PACFGH[15:12]

Disable REG_EN with GPIO_DBGCFG[4]

TIM1C4

Timer 1 Channel 4 input

Cannot be remapped

REG_EN

External regulator open drain output

Enabled after reset

PB3

I/O

Digital I/O

TIM2C3

(see also Pin 22)

Timer 2 channel 3 output

Enable remap with TIM2_OR[6]

Enable timer output in TIM2_CCER

Select alternate output function with GPIO_PBCFGL[15:12]

TIM2C3

(see also Pin 22)

Timer 2 channel 3 input

Enable remap with TIM2_OR[6]

SC1nCTS

UART CTS handshake of Serial Controller 1

Enable with SC1_UARTCFG[5]

Select UART with SC1_MODE

SC1SCLK

SPI master clock of Serial Controller 1

Either disable timer output in TIM2_CCER,



or disable remap with TIM2_OR[6]

Enable master with SC1_SPICFG[4]

Select SPI with SC1_MODE

Select alternate output function with GPIO_PBCFGL[15:12]

SC1SCLK

SPI slave clock of Serial Controller 1

Enable slave with SC1_SPICFG[4]

Select SPI with SC1_MODE

Table 6.1. EM358x Pin Descriptions (Continued)

Pin #

Signal

Direction

Description

Note:

1. IRQC and IRQD external interrupts can be mapped to any digital I/O pin using the GPIO_IRQCSEL and

GPIO_IRQDSEL registers.
