ASPI-8040S

ELECTRICAL SPECIFICATIONS:

30332 Esperanza, Rancho Santa Margarita, California92688

Revised: 02.03.14

Visit www.abracon.com for Terms & Conditions of Sale

Wire Wound Magnetically Shielded SMD Power Inductor

FEATURES:

APPLICATIONS:

• Shielded magnetics, low radiation

• Large Terminal surface for good PCB bonding

• Low DCR, High Energy storage, suitable for large currents

• Ideal for a variety of DC-DC converter inductor applications

• Partable communication equipment

• OA equipment

• LCD, DVD, modem, set-top box

• DC/DC converters

Abracon P/N:

ASPI-8040S Series

Operating Temperature

-40ºC to +125ºC

Storage Temperature

-10ºC to +40ºC and 70% R.H.

8.0 x 8.0 x 4.2mm

ABRACON IS

ISO9001:2008

CERTIFIED

Part Number

ASPI-8040S-

Inductance Code

Inductance

L Tolerance

DC Resistance

(±30%)

Saturation

Current

Temperature

Rise Current

Min. Self resonant

frequency

Units

μH

−

Ω

A

A

MHz

Symbol

L

N, M

DCR

Isat

Irms

SRF

ASPI-8040S-R82

0.82

N

0.008

13.8

6.30

94

ASPI-8040S-1R0

1.0

N

0.008

9.85

6.30

89

ASPI-8040S-1R5

1.5

N

0.010

8.15

5.65

67

ASPI-8040S-2R0

2.0

N

0.012

9.25

5.15

43

ASPI-8040S-2R2

2.2

N

0.012

7.10

5.15

41

ASPI-8040S-3R0

3.0

N

0.014

6.10

4.70

32

ASPI-8040S-3R3

3.3

N

0.017

6.50

4.40

27

ASPI-8040S-3R6

3.6

N

0.017

7.52

4.35

30

ASPI-8040S-3R9

3.9

N

0.017

5.75

4.35

26

ASPI-8040S-4R7

4.7

N

0.019

5.90

4.10

24

ASPI-8040S-5R1

5.1

N

0.019

4.70

4.05

22

ASPI-8040S-5R6

5.6

N

0.021

6.00

3.85

24

ASPI-8040S-6R2

6.2

N

0.021

4.45

3.85

20

ASPI-8040S-6R8

6.8

M

0.024

4.55

3.60

20

ASPI-8040S-8R2

8.2

M

0.026

4.20

3.45

17

ASPI-8040S-100

10

M

0.029

3.60

3.30

15

ASPI-8040S-150

15

M

0.047

2.95

2.60

12

ASPI-8040S-180

18

M

0.053

2.70

2.40

11

ASPI-8040S-220

22

M

0.069

2.40

2.10

9.5

ASPI-8040S-270

27

M

0.078

2.15

2.00

9.2

ASPI-8040S-330

33

M

0.097

2.05

1.80

7.8

ASPI-8040S-360

36

M

0.102

2.00

1.75

7.8

ASPI-8040S-390

39

M

0.107

1.95

1.70

7.8

ASPI-8040S-430

43

M

0.113

1.90

1.65

7.8

ASPI-8040S-470

47

M

0.136

1.75

1.55

6.4

ASPI-8040S-510

51

M

0.142

1.70

1.50

6.4

ASPI-8040S-560

56

M

0.148

1.55

1.45

6.4

ASPI-8040S-620

62

M

0.182

1.50

1.30

6.4

ASPI-8040S-680

68

M

0.196

1.45

1.25

4.9

ASPI-8040S-750

75

M

0.211

1.35

1.20

4.9

ASPI-8040S-820

82

M

0.225

1.30

1.15

5.9

ASPI-8040S-910

91

M

0.272

1.20

1.05

4.9

ASPI-8040S-101

100

M

0.290

1.15

1.00

4.2
