Product family data sheet

and SC3Technology®are registered trademarks and the Cree logo is a trademark of Cree, Inc. UL® and the UR logo are registered trademarks of UL LLC.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

Cree® XLamp® MK-R LEDs

PRoDuCt DEsCRiPtion

Built on Cree’s revolutionary SC³ Technology® platform, the

XLamp® MK-R LeD brings new levels of price and performance

to directional LeD arrays, enabling lighting manufacturers to

create the next generation of high-lumen indoor and outdoor

LeD lighting systems. In single-LeD systems, the XLamp MK-R

LeD, with easyWhite® color binning, provides the LeD industry’s

tightest unit-to-unit color consistency. For systems using multiple

LeDs, the MK-R enables manufacturers to use fewer LeDs while

maintaining light output and color consistency, which translates

to lower system cost.

The XLamp MK-R LeD is optimized for directional lighting

applications and is a welcome addition to applications requiring

high lumen output, a compact optical source and a broad palette

of color temperature and CRI values.

FEAtuREs

• Available in ANSI white bins as well as 4-step and 2-step

EasyWhitebinsat2700 K,3000 K,3500 K,4000 K,4500 K

and5000 KCCT

• Twovoltageoptions:6 V&12 V

• Lowthermalresistance:1.7 °C/W

• Maximumjunctiontemperature:150 °C

• Binnedat85 °C

• Viewingangle:120°

• Available in cool white, 70-, 80- and 90-CRI minimums

• Unlimitedfloorlifeat≤30 ºC/85%RH

• Reflowsolderable-JEDECJ-STD-020C

• electrically neutral thermal path

• RoHSandREAChcompliant

• UL®recognizedcomponent(E349212)
