14. Special Notes: NDG 48-VFQFN Package Assembly

Unopened dry packaged parts have a one-year shelf life.

The HIC indicator card for newly-opened dry packaged parts should be checked. If there is any moisture content, the parts must be baked for

a minimum of 8 hours at 125˚C within 24 hours prior to the assembly reflow process.

15. Marking Diagram

1. Line 1: Company name and part number.

2. Line 2: -R is part of the part number, which is followed by the package code.

3. Line 3: “YYWW” is the last two digits of the year and two digits for the week that the

part was assembled. # is the device step.“$” denotes the mark code.

16. Ordering Information

Orderable Part

Number

Description and Package

MSL Rating

Shipping

Package

Ambient

Temperature

P9242-RNDGI8

P9242-R Wireless Power Receiver for 15W

Applications, 48-VFQFN (6 x 6 mm) package (NDG48)

MSL1

Tape and reel

0°C to +85°C
