6 / 48 page

Absolute maximum ratings and operating conditions

TS4621B

6/48

Doc ID 022194 Rev 2

Absolute maximum ratings and operating conditions

Table 1.

Absolute maximum ratings

Symbol

Parameter

Value

Unit

VCC

Supply voltage (1) during 1ms.

All voltage values are measured with respect to the ground pin.

5.5

Vin+,Vin-

Input voltage referred to ground

+/- 1.2

Tstg

Storage temperature

-65 to +150

°C

Maximum junction temperature(2)

Thermal shutdown is activated when maximum junction temperature is reached.

150

°C

Rthja

Thermal resistance junction to ambient (3)

The device is protected from over-temperature by a thermal shutdown mechanism, active at 150° C.

200

°C/W

Power dissipation

Internally limited(4)

Exceeding the power derating curves for long periods may provoke abnormal operation.

ESD

Human body model (HBM)(5)

All pins

VOUTR, VOUTL vs. AGND

Human body model: a 100 pF capacitor is charged to the specified voltage, then discharged through a

1.5 k

Ω resistor between two pins of the device. This is done for all couples of connected pin combinations

while the other pins are floating.

Machine model (MM), min. value(6)

Machine model: a 200 pF capacitor is charged to the specified voltage, then discharged directly between

two pins of the device with no external series resistor (internal resistor < 5

Ω). This is done for all couples of

connected pin combinations while the other pins are floating.

100

Charge device model (CDM)

All pins

VOUTR, VOUTL

500

750

IEC61000-4-2 level 4, contact(7)

IEC61000-4-2 level 4, air discharge(7)

The measurement is performed on an evaluation board, with ESD protection EMIF02-AV01F3.

+/- 8

+/- 15

Lead temperature (soldering, 10 sec)

260

°C
