Page: 4/13

High Power Rating Electrical Specifications (PWR)

Type

Power

Rating

at 70℃

Operating

Temp.

Range

Max

Operating

Voltage

Max

Overloading

Voltage

Resistance Tolerance

(%)

Resistance

Range

(Ω)

TCR

PPM/℃

PWR03

(0603)

1/8W, 1/5W

-55 ~ +155℃ 50V

100V

±0.5%

10~294

±200

±1%, ±5%

1~294

±200

±0.5%, ±1%, ±5%

300~1M

±100

PWR05

(0805)

1/4W

-55 ~ +155℃ 150V

300V

±0.5%

10~294

±200

±1%, ±5%

1~294

±200

±0.5%, ±1%, ±5%

300~20M

±100

PWR06

(1206)

1/2W

-55 ~ +155℃ 200V

400V

±0.5%

10~20

±200

±1%, ±5%

1~20

±200

±0.5%, ±1%, ±5%

20.5~20M

±100

PWR10

(2010)

1W

-55 ~ +155℃ 400V

800V

±0.5%

10~20

±200

±1%, ±5%

1~20

±200

±0.5%, ±1%, ±5%

20.5~20M

±100

Lower Resistance :(1~10)Ω.

Operating Voltage =

√( ���� ∗ ���� ) , or Max. Operating Voltage listed in above table whichever is lower.

Overloading Voltage = 2.5*

√( ���� ∗ ���� ) , or Max. Overloading Voltage listed in above table whichever is lower.

Optional specifications can be required.
