AD8392

Rev. 0 | Page 8 of 16

–10

–8

–6

–4

–2

02468

TIME (

µs)

–0.06

–0.04

–0.02

0.02

0.04

0.06

Figure 16. Small Signal Pulse Response

Quad Op Amp Circuit (Figure 29)

VS = ±12 V, RLOAD = 100 Ω, G = +5, 100 mV Step

CH1 200mV

Ω

CH2 1.00mV

Ω

M 50.0ns

A CH2

2.38V

OUTPUT

PD PINS

Figure 17. Power-Up Time: PD (1, 1) to PD (0, 0)

Quad Op Amp Circuit (Figure 29)

VS = ±12 V, RLOAD = 100 Ω, G = +5, VOUT = 1 V p-p

CH1 5.00V

Ω

CH2 5.00V

Ω

M1.00

µs

CH1

700mV

OUTPUT

INPUT

∆: 460ns

@: –1.32

µs

C2 p-p

21.4V

C1 p-p

27.0V

Figure 18. Input Overdrive Recovery

Quad Op Amp Circuit (Figure 29)

VS = ±12 V, RLOAD = 100 Ω, G = +1, VIN = 27 V p-p

–10

–8

–6

–4

–2

02468

TIME (

µs)

–2.5

–2.0

–1.5

–1.0

–0.5

0.5

1.0

1.5

2.0

2.5

Figure 19. Large Signal Pulse Response

Quad Op Amp Circuit (Figure 29)

VS = ±12 V, RLOAD = 100 Ω, G = +5, 4 V Step

CH1 200mV

ΩB

CH2 1.00V

ΩB

M 400ns

CH2

2.38V

OUTPUT

PD PINS

Figure 20. Power-Down Time: PD (0, 0) to PD (1, 1)

Quad Op Amp Circuit (Figure 29)

VS = ±12 V, RLOAD = 100 Ω, G = +5, VOUT = 1 V p-p

CH1 1.00V

Ω

CH2 5.00V

Ω

M1.00

µs

CH1

800mV

OUTPUT

INPUT

∆: 420ns

@: 2.84

µs

C2 p-p

21.8V

C1 p-p

6.00V

Figure 21. Output Overdrive Recovery

Quad Op Amp Circuit (Figure 29)

VS = ±12 V, RLOAD = 100 Ω, G = +5, VIN = 6 V p-p
