DATE

REVISION

CHANGE

Apr 19, 2018 FN8666.4 Updated Related Literature on page 1.

Ordering Information table on page 3:

Added Tape and Reel parts and Tape and Reel column. Updated Note 1.

Added ISL8117DEMO3Z and ISL8117DEMO4Z.

Page 19: Output Capacitor Selection section, fourth paragraph, first sentence:

Changed “The maximum capacitor value. . .” to: “The minimum capacitor value. . .”

Removed About Intersil section.

Updated Disclaimer.

Updated POD L16.4x4A from rev 3 to rev 4, changes since rev 3:

Updated bottom view: 2.40 to 2.45 +0.10/-0.152.45 (2 dimensions)

Updated typical recommend land pattern: 2.40 to 2.45

Jun 4, 2015

FN8666.3 Description, page 1 - changed "with 13 external components" to "with 10 external components".

On page 3, EN pin description - changed "When the voltage on the pin reaches 1.3V, the output becomes active" to "When

the voltage on the pin reaches 1.6V, the output becomes active".

On page 14, right column, changed "Thermal protection may be triggered if die temperature increases above +150°C due

to excessive power dissipation" to "Thermal protection may be triggered if die temperature increases above +160°C due

to excessive power dissipation".

On page 14, right column, changed "When the EN pin voltage is higher than 1.3V, the controller is enabled to initialize its

internal circuit" to "When the EN pin voltage is higher than 1.6V, the controller is enabled to initialize its internal circuit".

May 12, 2015 FN8666.2 Replaced Figures 1, 4, and 5.

Updated the MOD/SYNC Pin description on page 3.

May 6, 2015

FN8666.1 Added HTSSOP package/part information throughout datasheet.

On page 7, updated “IVINOP” parameter Typical value from “3mA” to “2.5mA”.

Added 2nd Paragraph to “Overvoltage Protection” section on page 17.

Apr 10, 2015 FN8666.0 Initial Release
