AD8045

Rev. A | Page 11 of 24

OUTPUT VOLTAGE (V p-p)

3.0

0.5

1.0

1.5

2.0

2.5

–40

–50

–60

–70

–80

–90

–100

–110

HD3 SOIC AND LFCSP

HD2 SOIC

HD2 LFCSP

G = +1

f = 10MHz

Figure 31. Harmonic Distortion vs. Output Voltage for Various Packages

OUTPUT VOLTAGE (V p-p)

2.5

0.5

0.7

0.9

1.1

1.3

1.5

1.7

1.9

2.1

2.3

–40

–60

–50

–70

–80

–90

–100

–110

G = +1

f = 10MHz

HD3 SOIC AND LFCSP

HD2 SOIC

HD2 LFCSP

Figure 32. Harmonic Distortion vs. Output Voltage for Various Packages

OUTPUT VOLTAGE STEP (V)

5

01

234

1600

1400

1200

1000

800

600

400

200

0

POSITIVE SLEW RATE

NEGATIVE SLEW RATE

Figure 33. Slew Rate vs. Output Voltage

TIME (ns)

25

0

5

10

15

20

0.15

0.10

0.05

0

–0.05

–0.10

–0.15

G = +1

Figure 34. Small Signal Transient Response for Various Supplies and Loads

30

Ω

10pF

1k

Ω

TIME (ns)

25

0

5

10

15

20

0.15

0.10

0.05

0

–0.05

–0.10

–0.15

G = +1

Figure 35. Small Signal Transient Response for Various Supplies and Loads

TIME (ns)

25

0

5

10

15

20

0.15

0.10

0.05

0

–0.05

–0.10

–0.15

G = +2

Figure 36. Small Signal Transient Response for Various Loads
