TIME (ns)

8

2

4

6

0

–4

–2

–6

–8

250ns/DIV

INPUT

OUTPUT

G = 2

Figure 37. Overdrive Recovery

TIME (ns)

100

50

25

75

0

–25

–50

–75

–100

10ns/DIV

Figure 38. Small Signal Transient Response for Various Feedback

Capacitances

TIME (ns)

100

50

25

75

0

–50

–25

–75

–100

20ns/DIV

Figure 39. Small Signal Transient Response for Various Capacitive Loads

2.0

–2.0

–1.5

–1.0

–0.5

0

0.5

1.5

1.0

50ns/DIV

INPUT

TIME (ns)

Figure 40. Settling Time (0.02%)

2V p-p

1V p-p

TIME (ns)

1.5

1.0

–0.5

0

0.5

–1.0

–1.5

20ns/DIV

Figure 41. Large Signal Transient Response for Various Feedback

Capacitances

TIME (ns)

1.5

0.5

1.0

0

–0.5

–1.0

–1.5

20ns/DIV

Figure 42. Large Signal Transient Response for Various Capacitive Loads
