Digital Fiber Sensor

FX-410 SERIES

170

Selection

Guide

Fibers

Fiber

Amplifiers

FX-500

FX-100

FX-300

FX-410

FX-311

FX-301-F7/

FX-301-F

FIBER

SENSORS

LASER

SENSORS

PHOTO-

ELECTRIC

SENSORS

MICRO

PHOTO-

ELECTRIC

SENSORS

AREA

SENSORS

LIGHT

CURTAINS /

SAFETY

COMPONENTS

PRESSURE /

FLOW

SENSORS

INDUCTIVE

PROXIMITY

SENSORS

PARTICULAR

USE

SENSORS

SENSOR

OPTIONS

SIMPLE

WIRE-SAVING

UNITS

WIRE-SAVING

SYSTEMS

MEASURE-

MENT

SENSORS

STATIC

ELECTRICITY

PREVENTION

DEVICES

LASER

MARKERS

PLC

HUMAN

MACHINE

INTERFACES

ENERGY

CONSUMPTION

VISUALIZATION

COMPONENTS

FA

COMPONENTS

MACHINE

VISION

SYSTEMS

UV

CURING

SYSTEMS

Amplifiers Quick-connection cable is not supplied with the amplifier. Please order it separately.

Type

Appearance

Model No.

Emitting element

Output

FX-411

Red LED

NPN open-collector transistor

FX-411B

Blue LED

FX-411G

Green LED

FX-411P

Red LED

PNP open-collector transistor

FX-411BP

Blue LED

FX-411GP

Green LED

FX-412 (Note)

Red LED

NPN open-collector transistor

FX-412B (Note)

Blue LED

FX-412G (Note)

Green LED

Note: The

FX-412□ has a threshold value adjuster that can be adjusted with your fingers.

Quick-connection cables Quick-connection cable is not supplied with the amplifier. Please order it separately.

Type

Model No.

Description

Main cable

(3-core)

CN-73-C1

Length: 1 m 3.281 ft

0.2 mm2 3-core cabtyre cable,

with connector on one end

Cable outer diameter: ø3.3 mm

ø0.130 in

CN-73-C2

Length: 2 m 6.562 ft

CN-73-C5

Length: 5 m 16.404 ft

Sub cable

(1-core)

CN-71-C1

Length: 1 m 3.281 ft

0.2 mm2 1-core cabtyre cable,

with connector on one end

Cable outer diameter: ø3.3 mm

ø0.130 in

CN-71-C2

Length: 2 m 6.562 ft

CN-71-C5

Length: 5 m 16.404 ft

Main cable

• CN-73-C□

• CN-71-C□

Sub cable

End plates End plates are not supplied with the amplifier. Please order them separately when the amplifiers are mounted in cascade.

Appearance

Model No.

Description

MS-DIN-E

When cascading multiple amplifiers, or when it

moves depending on the way it is installed on a

DIN rail, these end plates clamp amplifiers into

place on both sides. Make sure to use end plates

when cascading multiple amplifiers together.

Two pcs. pet set

ORDER GUIDE

Designation

Model No.

Description

Amplifier

mounting bracket

MS-DIN-2

Mounting bracket for amplifier

Fiber amplifier

protection seal

FX-MB1

10 sets of 2 communication window seals and 1 connector seal

Communication window seal:

It prevents malfunction due to transmission signal from another

amplifier, as well as, prevents effect on another amplifier.

Connector seal:

It prevents contact of any metal, etc., with the pins of the

quick-connection cable.

Amplifier mounting bracket

• MS-DIN-2

Fiber amplifier protection seal

• FX-MB1

Communication

window seal

Connector seal

OPTIONS
