FH-Series

21

*1 The image acquisition time does not include the image conversion processing time of the sensor controller.

The camera image input time varies depending on the sensor controller model, number of cameras, and camera settings. Check before you use the camera.

*2 Up to four cameras of this model can be connected to one controller. Up to eight cameras including other models can be connected to an FH-5550-20, 5050-20 or

2050-20.

*3 Frame rate in high speed mode when the camera is connected using two camera cables. For other conditions, refer to the table on the next page.

*4 The image acquisition time does not include the image conversion processing time of the sensor controller.

*5 Two Camera ports of the controller are used per one camera.

*6 Up to 5 m Camera Cable length.

Camera Cables

*1 This Cable has an L-shaped connector on the Camera end.

*2 The maximum cable length depends on the camera being connected, and the model and length of the cable being used. For further information, refer to the

Cameras / Cables Connection Table and Maximum Extension Length Using Cable Extension Units FZ-VSJ table.

When a High-speed Digital CMOS Camera FH-S

@02/-S@04/-S@12/-S@X03/-S@X05/-S@X12/-S@21R is used in the high speed mode of transmission speed, two

camera cables are required.

*3 Insert the cables length into

@ in the model number as follows. 2 m = 2, 3 m = 3, 5 m = 5, 10 m = 10

Small Digital

CCD Cameras

(Lens required)

Lenses for small

camera required

300,000-pixel flat type

Color

12.5 ms

FZ-SFC

Monochrome

FZ-SF

300,000-pixel pen type

Color

12.5 ms

FZ-SPC

Monochrome

FZ-SP

Intelligent

Compact Digital

CMOS Camera

Built-in lens

Narrow view

Color

16.7 ms

FZ-SQ010F

Standard view

Color

FZ-SQ050F

Wide View (long-distance)

Color

FZ-SQ100F

Wide View (short-distance)

Color

FZ-SQ100N

Model

FH-

SM02

FH-

SC02

FH-

SM04

FH-

SC04

FH-

SM12

FH-

SC12

FH-

SMX

FH-

SCX

FH-

SMX01

FH-

SCX01

FH-

SMX03

FH-

SCX03

FH-

SMX05

FH-

SCX05

FH-

SMX12

FH-

SCX12

FH-

SM21R

FH-

SC21R


Acquisition

Time

*4

2Cables

*5

High

Speed

Mode *6

4.6 ms

8.5 ms

25.7 ms

---

---

6.6 ms

10.3 ms

24.9 ms

42.6 ms

Standard

Mode

9.7 ms

17.9 ms

51.3 ms

---

---

14.1 ms

22.1 ms

53.5 ms

90.1 ms

1 Cables

High

Speed

Mode *6

9.2 ms

17.0 ms

51.3 ms

1.9 ms

6.5 ms

13.2 ms

20.6 ms

50.0 ms

83.3 ms

Standard

Mode

19.3 ms

35.8 ms

102.0 ms

3.8 ms

14.7 ms

28.2 ms

44.1 ms

106.4 ms

175.4 ms

Item

Descriptions

Model *3

Camera Cable

Cable length: 2 m, 3 m, 5 m, or 10 m *2

FZ-VS3

@M

Bend resistant Camera Cable

Cable length: 2 m, 3 m, 5 m, or 10 m *2

FZ-VSB3

@M

Super Bend resistant Camera Cable

Cable length: 5 m or 10 m

FZ-VSBX

@M

Right-angle Camera Cable *1

Cable length: 2 m, 3 m, 5 m, or 10 m *2

FZ-VSL3

@M

Bend resistant Right-angle Camera Cable *1

Cable length: 2 m, 3 m, 5 m, or 10 m *2

FZ-VSLB3

@M

Long-distance Camera Cable

Cable length: 15 m *2

FZ-VS4 15M

Long-distance Right-angle Camera Cable *1

Cable length: 15 m *2

FZ-VSL4 15M

Cable Extension Unit

Up to two Extension Units and three Cables can be connected. (Maximum cable length: 45 m *2)

FZ-VSJ

Item

Lens mount

Descriptions

Color /

Monochrome

Image Acquisition

Time *1

Model
