SC1302A/B/C/D/E/F

4

Parameter

Symbol

Conditions

Min

Typ

Max

Units

Input

High Level Input Voltage

V

IH

0 < V

IN

< V

CC

2.0

V

Low Level Input Voltage

V

IL

0 < V

IN

< V

CC

0.8

V

Input Current

I

IN

0 < V

IN

< V

CC

, Non-inverting Input(s)

of SC1302A/C/D/F

13

18.5

μA

0 < V

IN

< V

CC

, Inverting Input(s)

of SC1302B/C/E/F

-8

μA

Output

Output Peak Current

I

PK_SOURCE

V

OUT

= 0.5V, t

PW

< 10 μs

1600

mA

I

PK_SINK

V

OUT

= V

CC

- 0.5V, t

PW

< 10 μs

1600

mA

Shutdown for SC1302A/B/C

SHDN Input Voltage High

V

SHDN

2V

SHDN Input Voltage Low

V

SHDN

0.3

V

SHDN Pin current

I

SHDN

V

SHDN

= 5V

32

40

μA

Thermal Shutdown

T

J_OT

150

°C

10

°C

Electrical Characteristics (continued)

AC Electrical Characteristics

Parameter

Symbol

Conditions

Min

Typ

Max

Units

t

R

See Timing Diagram

20

ns

t

F

See Timing Diagram

20

ns

t

D1

T

A

= -40°C ~ 125°C

53

70

ns

t

D2

T

A

= -40°C ~ 125°C

41

60

ns

Notes:

(1) Guaranteed by design

(2) Negative sign indicates that the input current flows out of the device.

Unless otherwise specified, T

A

= T

J

= 25ºC, V

CC

=12V, V

EN

= 5V, C

L

= 1000pF

Unless otherwise specified, -40ºC < T

A

= T

J

<125°C, V

CC

= 12V, V

IN

= 5V, V

EN

=5V (SC1302A/B/C), V

SHDN

= 5V (SC1302A/B/C)
