SC1302A/B/C/D/E/F

3

Exceeding the above specifications may result in permanent damage to the device or device malfunction. Operation outside of the parameters

specified in the Electrical Characteristics section is not recommended.

Absolute Maximum Ratings

Supply Voltage V

CC

(V) . . . . . . . . . . . . . . . . . . . . . . -0.3 to +20

Input Voltages (V) . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3 to V

CC

Peak Output Currents (A) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Enable Voltage SC1302A/B/C (V) . . . . . . . . . . . -0.3 to V

CC

Shutdown Voltage SC1302A/B/C (V) . . . . . . . . -0.3 to V

CC

Continuous Power Dissipation (W). . . . . . Internally limited

ESD Protection Level (kV) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Recommended Operating Conditions

Operating Temperature Range (°C) . . . . . . -40 < T

J

< +125

Operating Supply Voltage (V) . . . . . . . . . . . . . . . -0.3 to 16.5

Thermal Information

Thermal Resistance, Junction to Ambient MSOP(°C/W). .206

Thermal Resistance, Junction to Ambient SIOC(°C/W) . . .165

Maximum Junction Temperature (°C) . . . . . . . . . . . . . . +150

Storage Temperature Range (°C) . . . . . . . . . . . -65 to +150

Lead Temperature (Soldering)10s (°C) . . . . . . . . . . . . . +260

Unless otherwise specified, -40ºC < T

A

= T

J

<125°C, V

CC

= 12V, V

IN

= 5V, V

EN

=5V (SC1302A/B/C), V

SHDN

= 5V (SC1302A/B/C)

Parameter

Symbol

Conditions

Min

Typ

Max

Units

Supply Current

Quiescent Current

I

Q

V

CC

< V

START

1

1.8

mA

Quiescent Current

I

Q

V

EN

= V

SHDN

= 3V for SC1302A/B/C, V

INA

= V

INB

= 3V

5.7

8.1

mA

Quiescent Current

I

Q

V

SHDN

= 0V for SC1302A/B/C

3

8

μA

Under-Voltage Lockout

Threshold Voltage

V

START

V

SHDN

= V

EN

= 3V for SC1302A/B/C, V

INA

= V

INB

= 3V

4.2

4.5

4.7

V

Hysteresis

V

SHDN

= V

EN

= 3V for SC1302A/B/C, V

INA

= V

INB

= 3V

250

320

475

mV

Enable for SC1302A/B/C

Enable Voltage

V

EN

0 < V

EN

< V

CC

2.0

V

Disable Voltage

V

EN

0 < V

EN

< V

CC

0.8

V

t

D_EN

EN from low to high

70

ns

t

D_DIS

EN from high to low

55

ns

Enable Input Current

I

EN

0 < V

IN

< V

CC

10

14

19

μA

DC Electrical Characteristics
