SC1302A/B/C/D/E/F

6

Pin Descriptions

Pin #

SC1302A/D SC1302B/E

SC1302C/F

Pin Function

1

EN/NC

EN/NC

EN/NC

Enable/Disable Control — When the EN is driven low, both outputs are low. When

left open, both outputs are low. Enable both drivers by tying EN pin to a voltage

greater than 2V. No connection on versions D, E, and F.

2

INA

INA

INA

TTL compatible input to driver A — When left open, Pin 7 is low.

3

GND

GND

GND

Ground connection

4

INB

INB

INB

TTL compatible input to driver B — When left open, Pin 5 is low.

5

OUTB

OUTB

OUTB

Output gate drive B for external MOSFET

6

VCC

VCC

VCC

Supply: +4.5V to +16.5V supply. During UVLO the outputs are held low.

7

OUTA

OUTA

OUTA

Output gate drive A for external MOSFET

8

SHDN/NC

SHDN/NC

SHDN/NC

Shutdown pin — Apply a voltage from 2V to VCC to enable device. Pull below 0.3V

for low-power shut down. No connection on versions D, E, and F.
