AD8420

Data Sheet

Rev. 0 | Page 16 of 28

100

100k

10k

FREQUENCY (Hz)

Figure 45. Current Noise Spectral Density vs. Frequency

1.5pA/DIV

1s/DIV

Figure 46. 0.1 Hz to 10 Hz Current Noise

100

10k

100k

FREQUENCY (Hz)

VS = ±15V, G = 15V/V

VS = +5V, G = 5V/V

Figure 47. Large Signal Frequency Response

0.02%/DIV

1V/DIV

20µs/DIV

VS = ±5V

1.78µs TO 0.1%

3.31µs TO 0.01%

Figure 48. Large Signal Pulse Response and Settling Time, G = 1

0.02%/DIV

4.5V/DIV

200µs/DIV

VS = ±5V

67µs TO 0.1%

138µs TO 0.01%

Figure 49. Large Signal Pulse Response and Settling Time, G = 10

0.02%/DIV

4.5V/DIV

20ms/DIV

VS = ±5V

600ms TO 0.1%

1.04ms TO 0.01%

Figure 50. Large Signal Pulse Response and Settling Time, G = 100
