K-Type® cable markers

Catalog 1654227

Dimensions not italicized are

Dimensions are shown for

USA: 1-800-522-6752

South America: 55-11-3611-1514

Revised 04-07

in millimeters while dimensions

reference purposes only.

Canada: 1-905-470-4425

Hong Kong: 852-2735-1628

in inches are italicized.

Specifications subject

Mexico: 01-800-733-8926

Japan: 81-44-844-8013

www.tycoelectronics.com

to change.

C. America: 52-55-5-729-0425

UK: 44-141-810-8967

Pre-Printed Wire and Cable Markers

1361 1 4 01

Part numbering system

Legend code

Color code

Packaging code

Product/size code

K-Type® markers are used to identify wire bundles, cables, pipes

and conduits using specially designed oval shaped, individual

characters that slide on to a PVC carrier, which is then attached to

the substrate using cable ties. K-Type® markers are ideal for post

termination applications or where retrofit is anticipated.

These markers are supplied yellow with black legends and in the

standard International colour code option and are supplied on

reels. K-Type® markers come in one standard size to fit carrier

strips that can hold from 7 to 18 markers and are made from a

plasticized PVC material.

Features and benefits

I Versatile marking system for cables , cable bundles and conduit

I Elliptical marker profile allows easy fitting to carrier strips

Temperature rating

Operating temperature range

–40°C to +70°C

–40°F to +158°F

Specifications/approvals

Tyco Electronics

TTDS- 025
