TKM Hand writable booklet self-laminating labels

Catalog 1654227

Dimensions not italicized are

Dimensions are shown for

USA: 1-800-522-6752

South America: 55-11-3611-1514

Revised 04-07

in millimeters while dimensions

reference purposes only.

Canada: 1-905-470-4425

Hong Kong: 852-2735-1628

in inches are italicized.

Specifications subject

Mexico: 01-800-733-8926

Japan: 81-44-844-8013

www.tycoelectronics.com

to change.

C. America: 52-55-5-729-0425

UK: 44-141-810-8967

Self-Laminating Labels

Tyco Electronics TKM is a self writable, clear vinyl film with a

permanent acrylic adhesive, supplied with a white writable area,

which is over-laminated upon application with the clear portion of

the label.

TKM labels are a quick, simple and durable form of wire, cable and

pipe identification.

Features and benefits

I Manufactured with a white coated area for writing on, and with

I a clear wrap to wind around a wire or cable to cover the written

I legend and to protect it against impurities that would cause the

I label to become illegible

I Protects printed information from chemicals and frequent

I handling

I Supplied in a handy pocket size booklet

I Designed to withstand exposure to Solvents, salts, alkalis

and water

Temperature rating

Operating temperature range

–54°C to +82°C

–65°F to +180°F

Specifications/Approvals

Tyco Electronics

TTDS-056

TKM 75 WE - N

Part numbering system

Standard Packaging

Color (WE=White)

Label size

Product family
