Snap-On wire markers

Catalog 1654227

Dimensions not italicized are

Dimensions are shown for

USA: 1-800-522-6752

South America: 55-11-3611-1514

Revised 04-07

in millimeters while dimensions

reference purposes only.

Canada: 1-905-470-4425

Hong Kong: 852-2735-1628

in inches are italicized.

Specifications subject

Mexico: 01-800-733-8926

Japan: 81-44-844-8013

www.tycoelectronics.com

to change.

C. America: 52-55-5-729-0425

UK: 44-141-810-8967

Pre-Printed Wire and Cable Markers

Tyco Electronics snap-on markers are convenient and easy to use.

These markers are supplied on a ‘wand’ applicator that simplifies

and reduces installation time, and saves on the cost of marking.

Snap-on wire markers are designed to stand the test of time, pre-

venting costly re-work before the life of the equipment ends. This is

why Tyco Electronics snap-on markers are found today in power

stations, oil refineries, offshore platforms, and other major projects

around the world.

Features and benefits

I Snap-on markers are the perfect way to permanently and

rapidly mark cables, wires, leads, and cores after

termination and installation

I Easy to alter identification on cables that are already marked

I Secure grip for positive fixing to cable

I The high elasticity of the marker enables all types of installation

and conduction material to be permanently

marked without damage

I Applicator has a patented slit to prevent over-expansion of the

marker during application

I Made from polyoxymethylene which guarantees strength,

dimensional stability, low moisture absorption, and

resistance to chemicals

I Resistant against oils, cleaning agents, fuels, and

alkaline solutions

I Zero-halogen material

I Ten sizes for cable diameters 0.04" to 0.75"

(1.0mm to 19.0mm)

I Color-coded option

Specifications/approvals

Tyco Electronics

TTDS- 094

Temperature rating

Operating temperature range

–40°C to +106°C

–40°F to +223°F

STD 06 W -4

Part numbering system

Legend code

Color code (W=white)

Size

Snap-on Marker
