B189

s Single Row Right Angle Pin Header

Unit: mm

Note 1.The quantity at the specific No. "None" is delivered by the bag unit (100 pcs.). If needed, please order the product per bag.

Note 2.The 4 and 6 contact connector contains the concave portion to prevent miss-insertion in the center at one point, which is

different from the above figure.

Part Number

DF1BZ- 2P-2.5DS

DF1BZ- 3P-2.5DS

DF1BZ- 4P-2.5DS

DF1BZ- 5P-2.5DS

DF1BZ- 6P-2.5DS

DF1BZ- 7P-2.5DS

DF1BZ- 8P-2.5DS

DF1BZ- 9P-2.5DS

DF1BZ-10P-2.5DS

DF1BZ-11P-2.5DS

DF1BZ-12P-2.5DS

DF1BZ-13P-2.5DS

DF1BZ-14P-2.5DS

DF1BZ-15P-2.5DS

DF1BZ-16P-2.5DS

DF1BZ-18P-2.5DS

DF1BZ-20P-2.5DS

Tin plated

Gold plated

CL No.

CL541-2034-0

CL541-2035-2

CL541-2036-5

CL541-2037-8

CL541-2038-0

CL541-2039-3

CL541-2040-2

CL541-2041-5

CL541-2042-8

CL541-2043-0

CL541-2044-3

CL541-2045-6

CL541-2046-9

CL541-2047-1

CL541-2048-4

CL541-2049-7

CL541-2050-6

Part Number

DF1B- 2P-2.5DS(01)

DF1B- 3P-2.5DS(01)

DF1B- 4P-2.5DS(01)

DF1B- 5P-2.5DS(01)

DF1B- 6P-2.5DS(01)

DF1B- 7P-2.5DS(01)

DF1B- 8P-2.5DS(01)

DF1B- 9P-2.5DS(01)

DF1B-10P-2.5DS(01)

_________

DF1B-12P-2.5DS(01)

_________

DF1B-14P-2.5DS(01)

DF1B-15P-2.5DS(01)

DF1B-16P-2.5DS(01)

DF1B-18P-2.5DS(01)

DF1B-20P-2.5DS(01)

CL No.

541-0225-7-01

541-0226-0-01

541-0227-2-01

541-0228-5-01

541-0229-8-01

541-0230-7-01

541-0231-0-01

541-0232-2-01

541-0233-5-01

_________

541-0235-0-01

_________

541-0237-6-01

541-0238-9-01

541-0239-1-01

541-0240-0-01

541-0241-3-01

Number of Contacts

2

3

4

5

6

7

8

9

10

_________

12

_________

14

15

16

18

20

A

2.5

5.0

7.5

10.0

12.5

15.0

17.5

20.0

22.5

___

27.5

___

32.5

35.0

37.5

42.5

47.5

B

7.5

10.0

12.5

15.0

17.5

20.0

22.5

25.0

27.5

___

32.5

___

37.5

40.0

42.5

47.5

52.5

RoHS

YES
