B193

s Single Row In-line Plug(Simple Lock Type)

Note 1.The quantity at the specific No. "None" is delivered by the bag unit (100 pcs.). If needed, please order the product per bag.

Note 2.The 2 contacts connector contains the concave portion to prevent miss-insertion in the center area at one point, which is

different from the above figure.In addition, the 3 to 7 contact connectors contain the concave portion at both sides.

Note 1.The installation hole size C according to panel board thickness.

Note 2.Fabricate installation holes so that no burr can occur.

Note 3.At the panel tab portion, use the surface that will not be rounded.

Unit: mm

Part Number

CL No.

DF1BA- 8EP-2.5RC

DF1BA- 9EP-2.5RC

DF1BA-10EP-2.5RC

DF1BA-12EP-2.5RC

541-0706-5

541-0707-8

541-0708-0

541-0710-2

8

9

10

12

17.5

20

22.5

27.5

22.1

24.6

27.1

32.1

Yes

Number of Contacts

A

B

RoHS

Part Number

CL No.

DF1BA- 2EP-2.5RC

DF1BA- 3EP-2.5RC

DF1BA- 4EP-2.5RC

DF1BA- 5EP-2.5RC

DF1BA- 6EP-2.5RC

DF1BA- 7EP-2.5RC

541-0700-9

541-0701-1

541-0702-4

541-0703-7

541-0704-0

541-0705-2

2

3

4

5

6

7

2.5

5

7.5

10

12.5

15

7.1

9.6

12.1

14.6

17.1

19.6

Yes

Number of Contacts

A

B

RoHS

KApplicable Socket: DF1B-*S-2.5R

Contact Inserted.

B Panel Cutouts

Unit: mm

Applicable Plug

Number of Contacts

DF1BA- 2EP-2.5RC

DF1BA- 3EP-2.5RC

DF1BA- 4EP-2.5RC

DF1BA- 5EP-2.5RC

DF1BA- 6EP-2.5RC

DF1BA- 7EP-2.5RC

DF1BA- 8EP-2.5RC

DF1BA- 9EP-2.5RC

DF1BA-10EP-2.5RC

DF1BA-12EP-2.5RC

2

3

4

5

6

7

8

9

10

12

0.5 to 1.2

Panel Board Thickness (Note 1)

C

11.2

13.7

16.2

18.7

21.2

23.7

26.2

28.7

31.2

36.2

1.3 to 1.6

11.9

14.4

16.9

19.4

21.9

24.4

26.9

29.4

31.9

36.9

1.7 to 2.0

12.6

15.1

17.6

20.1

22.6

25.1

27.6

30.1

32.6

37.6

D

7.3

9.8

12.3

14.8

17.3

19.8

22.3

24.8

27.3

32.3

Note 3

Panel
