B192

sDouble Row Right Angle Pin Header

Note 1.The quantity at the specific No. "None" is delivered by the bag unit (100 pcs.). If needed, please order the product per bag.

Note 2.The 4 and 6 contact connector contains the concave portion to prevent miss-insertion in the center area at one point, which is

different from the above figure.

Unit: mm

Part Number

DF1BZ- 4DP-2.5DS

DF1BZ- 6DP-2.5DS

DF1BZ- 8DP-2.5DS

DF1BZ-10DP-2.5DS

DF1BZ-12DP-2.5DS

DF1BZ-14DP-2.5DS

DF1BZ-16DP-2.5DS

DF1BZ-18DP-2.5DS

DF1BZ-20DP-2.5DS

DF1BZ-22DP-2.5DS

DF1BZ-24DP-2.5DS

DF1BZ-26DP-2.5DS

DF1BZ-28DP-2.5DS

DF1BZ-30DP-2.5DS

DF1BZ-34DP-2.5DS

DF1BZ-36DP-2.5DS

DF1BZ-40DP-2.5DS

Tin plated

Gold plated

CL No.

541-2051-9

541-2052-1

541-2053-4

541-2054-7

541-2055-0

541-2056-2

541-2057-5

541-2058-8

541-2059-0

541-2060-0

541-2061-2

541-2062-5

541-2063-8

541-2064-0

541-2065-3

541-2066-6

541-2067-9

Part Number

DF1B- 4DP-2.5DS(01)

DF1B- 6DP-2.5DS(01)

DF1B- 8DP-2.5DS(01)

DF1B-10DP-2.5DS(01)

DF1B-12DP-2.5DS(01)

DF1B-14DP-2.5DS(01)

DF1B-16DP-2.5DS(01)

DF1B-18DP-2.5DS(01)

DF1B-20DP-2.5DS(01)

DF1B-22DP-2.5DS(01)

DF1B-24DP-2.5DS(01)

DF1B-26DP-2.5DS(01)

DF1B-28DP-2.5DS(01)

DF1B-30DP-2.5DS(01)

DF1B-34DP-2.5DS(01)

DF1B-36DP-2.5DS(01)

DF1B-40DP-2.5DS(01)

CL No.

541-0654-3-01

541-0655-6-01

541-0656-9-01

541-0632-0-01

541-0633-3-01

541-0634-6-01

541-0635-9-01

541-0636-1-01

541-0637-4-01

541-0638-7-01

541-0639-0-01

541-0640-9-01

541-0641-1-01

541-0642-4-01

541-0644-0-01

541-0645-2-01

541-0647-8-01

Number of Contacts

4

6

8

10

12

14

16

18

20

22

24

26

28

30

34

36

40

B

2.5

5.0

7.5

10.0

12.5

15.0

17.5

20.0

22.5

25.0

27.5

30.0

32.5

35.0

37.5

42.5

47.5

A

7.5

10.0

12.5

15.0

17.5

20.0

22.5

25.0

27.5

30.0

32.5

35.0

37.5

40.0

42.5

47.5

52.5

RoHS

YES
