B191

s Double Row Straight Pin Header

+0.1

Unit: mm

Note 1.The quantity at the specific No. "None" is delivered by the bag unit (100 pcs.). If needed, please order the product per bag.

Note 2.The 4 and 6 contact connector contains the concave portion to prevent miss-insertion in the center area at one point, which is

different from the above figure.

Part Number

DF1BZ- 4DP-2.5DSA

DF1BZ- 6DP-2.5DSA

DF1BZ- 8DP-2.5DSA

DF1BZ-10DP-2.5DSA

DF1BZ-12DP-2.5DSA

DF1BZ-14DP-2.5DSA

DF1BZ-16DP-2.5DSA

DF1BZ-18DP-2.5DSA

DF1BZ-20DP-2.5DSA

DF1BZ-22DP-2.5DSA

DF1BZ-24DP-2.5DSA

DF1BZ-26DP-2.5DSA

DF1BZ-28DP-2.5DSA

DF1BZ-30DP-2.5DSA

DF1BZ-34DP-2.5DSA

DF1BZ-36DP-2.5DSA

DF1BZ-40DP-2.5DSA

Tin plated

Gold plated

CL No.

541-2017-0

541-2018-3

541-2019-6

541-2020-5

541-2021-8

541-2022-0

541-2023-3

541-2024-6

541-2025-9

541-2026-1

541-2027-4

541-2028-7

541-2029-0

541-2030-9

541-2031-1

541-2032-4

541-2033-7

Part Number

DF1B- 4DP-2.5DSA(01)

DF1B- 6DP-2.5DSA(01)

DF1B- 8DP-2.5DSA(01)

DF1B-10DP-2.5DSA(01)

DF1B-12DP-2.5DSA(01)

DF1B-14DP-2.5DSA(01)

DF1B-16DP-2.5DSA(01)

DF1B-18DP-2.5DSA(01)

DF1B-20DP-2.5DSA(01)

DF1B-22DP-2.5DSA(01)

DF1B-24DP-2.5DSA(01)

DF1B-26DP-2.5DSA(01)

DF1B-28DP-2.5DSA(01)

DF1B-30DP-2.5DSA(01)

DF1B-34DP-2.5DSA(01)

DF1B-36DP-2.5DSA(01)

DF1B-40DP-2.5DSA(01)

CL No.

541-0651-5-01

541-0652-8-01

541-0653-0-01

541-0616-4-01

541-0617-7-01

541-0618-0-01

541-0619-2-01

541-0620-1-01

541-0621-4-01

541-0622-7-01

541-0623-0-01

541-0624-2-01

541-0625-5-01

541-0626-8-01

541-0628-3-01

541-0629-6-01

541-0631-8-01

Number of Contacts

4

6

8

10

12

14

16

18

20

22

24

26

28

30

34

36

40

B

2.5

5.0

7.5

10.0

12.5

15.0

17.5

20.0

22.5

25.0

27.5

30.0

32.5

35.0

40.0

42.5

47.5

A

7.5

10.0

12.5

15.0

17.5

20.0

22.5

25.0

27.5

30.0

32.5

35.0

37.5

40.0

45.0

47.5

52.5

RoHS

YES
