F–16

Dimensions are shown: Inches (mm)

Specifications and dimensions subject to change

www.ck-components.com

F

16 [0.630]

ø 2 [ 0.079]

15/32-32, NS-2A

.464 (11,79)

1/4-40 uns-2A nut

.524 (13,3)

.331 (8,4)

15/32-32 NS-2A

ø .331 (8,4)

.477

(12,12)

.777

(19,74)

L41 Lever handle

PART NO.

481001000

WHITE

481002263

BLACK

481003000

RED

Material: Nylon

Finish: Matte

L42 Lever handle

PART NO.

481101000

WHITE

481102263

BLACK

481103000

RED

Material: Nylon

Finish: Matte

Fits Z3 Termination

female connector

PART NO.

530100000

Available in loose pieces.

NOTE: Additional nuts, locking rings

and lockwashers available

separately, see Section N.

Other colors available, consult

Customer Service Center.

7000 Series

Miniature Toggle Switches

SEAL

.383

(9,73)

.687

(17,45)

.312

(7,92)

Dim. 'A'

AVAILABLE HARDWARE

SP

.410 (10,41)

DP

.440 (11,18)

3P

.505 (12,83)

4P

.505 (12,83)

DIM ‘A’

NO.

POLES

E

EPOXY SEAL

I

EPOXY POTTED BASE

Cap

PART NO.

896801000

WHITE

896802000

BLACK

896803000

RED

Material: Polyethylene

Finish: Matte

Cap

PART NO.

763701000

WHITE

763702000

BLACK

763703000

RED

Material: Vinyl

Finish: Matte

Cap

PART NO.

706201000

WHITE

706202000

BLACK

706203000

RED

Material: Vinyl

Finish: Matte

Compatible with “bottom-wash” PC board cleaning methods.

Available with C, W-W5, Z & Z3 terminations only.

759D02000 Sealing Boot

703D02000 Sealing Boot

704D02000 Sealing Boot

NOTE: For use with S actuator style when combined

with D, H, H3, Y, and Y4 bushings

NOTE: For use with T and TP style actuators. Can

not be used for Switch Functions: 7103, 7203,

7303, 7403, 7107, 7207, 7307, 7407.

NOTE: For use with T, TP and T2P style actuators. Can not

be used for Switch Functions: 7103, 7203, 7303, 7403,

7107, 7207, 7307, and 7407.
