7000 Series

Miniature Toggle Switches

TERMINATIONS

Terminals &

Support

Actuator Shown

In Pos. 1

SECTION A-A

Actuator Shown

In Pos. 1

SECTION A-A

Terminals &

Support

.33 (8,4)

DIM 'A'

PC MOUNTING

.18

(4,6)

.33 TYP.

(8,4)

PC MOUNTING

7201MD9ABE

Horizontal Actuation

DPDT

7301MD9ABE

Horizontal Actuation

3PDT

AW1

.40 (10,2)

AW4

.50 (12,7)

DIM ‘A’

OPTION

CODE

A

RIGHT ANGLE, PC THRU-HOLE

A3

RIGHT ANGLE, SNAP-IN, PC THRU-HOLE

A

RIGHT ANGLE, PC THRU-HOLE

AW4

RIGHT ANGLE, EXTENDED, PC THRU-HOLE

AW1, AW4

RIGHT ANGLE, EXTENDED,

PC THRU-HOLE

Not available with I seal option.

Terminal bend radii and lead-in manufacturing option.

Not available with I seal option.

Terminal bend radii and lead-in manufacturing option.
