Digital Fiber Sensor

Glossary of terms / General precautions...P.983~ / P.986~

■

Taking fiber sensors to the next level

Conforming to

EMC Directive

The dual digital display allows users to check both the threshold

value and incident light intensity at the same time, allowing

for clear and intuitive control of the sensor’s functions. The

threshold value can be adjusted simply by pressing the

(UP)

key or the

(DOWN) key, so that the output operation can be

controlled with high precision, directly from the RUN mode.

Setup is made simple, using a dual digital display

Commercially-available connectors are used so that lead time and spare part numbers

can both be reduced

The connectors used are commercially-available connectors,

so that processing costs and lead time required for carrying

out processing after purchase of the sensors can be greatly

reduced. The same connection parts as the DP-100 series

of digital pressure sensors and the PM-64 series of micro

photoelectric sensors can be used.

Fiber selection................................. P.63~

■

General terms and conditions............. P.1

■

Sensor selection guide........P.11~ / P.61~

■

PNP output

type available

Timer

Light intensity

monitor

Interference

prevention

Automatic

sensitivity setting

Test input

Conventional (cable type)

From now on (built-in connector type)

Using cables with connectors

1 Sensor purchase and preparation

2 Harness processing by outside order

1 Sensor purchase and preparation

2 Harness processing by outside order

1 Purchase of sensors and cable with connectors

Conventional lead time

Customer

Harness

processor

Customer

Customer

Harness

processor

Sensor preparation

Sensor preparation

Harness Processing

Harness Processing

Sensor installation

Reduced

Sensor installation

Reduced

Sensor preparation Sensor installation

Lead time from now on

Lead time further reduced

Reduced

lead time

● Harness processing by outside order after sensor preparation

● Harness processing by outside order

Commercially-available press-fit connectors are used, so that the processing

costs for connection cables can be greatly reduced.

Threshold value

Incident light intensity

Connection with a

commercially-available

connector
