FT51A Advanced MCU with 8051 Compatible Core IC Datasheet

Version 1.5

Doc ument N o.: FT _000877

C learance N o.: FT DI#420

Address

Description

(0x65)

UART_TX_INT

UART Tx Interrupt Status

(0x66)

UART_RX_IEN

UART Rx Interrupt Enable

(0x67)

UART_RX_INT

UART Rx Interrupt Status

(0x68)

UART_LINE_CTRL

UART Line Control

(0x69)

UART_BAUD_0

UART Baud Rate Byte 0

(0x6A)

UART_BAUD_1

UART Baud Rate Byte 1

(0x6B)

UART_BAUD_2

UART Baud Rate Byte 2

(0x6C)

UART_FLOW_CTRL

UART Flow Control

(0x6D)

UART_FLOW_STAT

UART Flow Control Status

(0x70)

TIMER_CONTROL

TIMER Top Control

(0x71)

(0x74)

TIMER_CONTROL_1

TIMER_CONTROL_4

Timer Control Register 1 to 4

(0x75)

TIMER_INT

Timer Interrupt Status

(0x76)

TIMER_SELECT

Timer Select Register

(0x77)

TIMER_WDG

Watchdog Start Value

(0x78)

TIMER_WRITE_LS

Timer Start Value 7:0

(0x79)

TIMER_WRITE_MS

Timer Start Value 15:8

(0x7A)

TIMER_PRESC_LS

Timer Prescaler Value 7:0

(0x7B)

TIMER_PRESC_MS

Timer Prescaler Value 15:8

(0x7C)

TIMER_READ_LS

Timer Current Value 7:0

(0x7D)

TIMER_READ_MS

Timer Current Value 15:8

(0x80)

PWM_CONTROL

PWM Control Register

(0x81)

PWM_CTRL

PWM Control

(0x82)

PWM_PRESCALER

PWM PRESCALER Comparator value

(0x83)

PWM_CNT16_LSB

PWM COUNTER16 Comparator LSB

value

(0x84)

PWM_CNT16_MSB

PWM COUNTER16 Comparator MSB

value

(0x85)

(0x94)

PWM_CMP16_0_LSB

PWM_CMP16_7_MSB

PWM Comparator 0 LSB value to PWM

Comparator 7 MSB value

(0x95)

(0x9C)

PWM_OUT_TOGGLE_EN_0

PWM_OUT_TOGGLE_EN_7

PWM Out toggle enable register 0 to 7

(0x9D)

PWM_OUT_CLR_EN

PWM Out clear enable

(0x9E)

PWM_CTRL_BL_CMP8

PWM Control CMP8 value

(0x9F)

PWM_INIT

PWM Initialization register

(0xA0)

FIFO_CONTROL

FIFO Control Register

(0xA1)

FIFO_CTRL_STATUS

FIFO Control Status

(0xA2)

FIFO_RX_DATA

FIFO Receive Data

(0xA3)

FIFO_TX_DATA

FIFO Transmit Data

(0xA4)

FIFO_INTERRUPT_ENA

FIFO Interrupt Enable

(0xA5)

FIFO_INTERRUPT

FIFO Interrupt

(0xB0)

DMA_CONTROL_1

DMA Control Register

(0xB1)

DMA_ENABLE_1

IO DMA Enable Register

(0xB2)

DMA_IRQ_ENA_1

DMA IO Interrupt Enable & Control

(0xB3)

DMA_IRQ_1

DMA IO Interrupt Register

(0xB4)

DMA_SRC_MEM_ADDR_L_1

DMA IO Source Mem Addr Register

(Lower Bits)

(0xB5)

DMA_SRC_MEM_ADDR_U_1

DMA IO Source Mem Addr Register

(Upper Bits)

(0xB6)

DMA_DEST_MEM_ADDR_L_1

DMA IO Destination Mem Addr Register

(Lower Bits)

(0xB7)

DMA_DEST_MEM_ADDR_U_1

DMA IO Destination Mem Addr Register

(Upper Bits)
