4 Bluetooth RF Specifications

Unless otherwise stated, the specifications in this section apply when the operating conditions are within the limits

specified in Section 3.2, Recommended Operating Conditions. Functional operation outside these limits is not guar-

anteed.

All specifications are measured with a coax pigtail soldered to the PCB antenna feed point, with VDD = 3.0V and at a

room temperature of 25°C.

4.1 Summary RF Specifications

Table 8. Summary RF Specifications

Feature Supported

Description

Bluetooth Standard

Version 4.1

Frequency Band

2.400 GHz – 2.500 GHz

Channels (2MHz spacing)

3 x Advertising channels @ 2402 / 2426 / 2480 MHz

36 x Data channels

Maximum Raw Data Rate

1 Mbit/s

Maximum Application Data Rate

0.27 Mbit/s

Modulation Type

DSSS: GFSK (modulation index = 0.5)

Maximum RF Input

-10 dBm

Typical Receive Sensitivity

-94 dBm

Maximum RF Tx Output Power

+4 dBm

Carrier Frequency Accuracy

±20 ppm (24 MHz crystal, ±20 ppm stability @ 25°C)

4.2 Receiver Specifications

Table 9. Receiver Performance Specifications

Parameter

Condition/Notes

Min.

Typical

Max.

Unit

Frequency Range

–

2402

–

2480

MHz

Operating Temperature

–

-30

–

+85

°C

Receive Sensitivity

200 x 37-byte packets with 30.8% PER

–

-94

–

dBm

Maximum Receive Level

-10

–

–

dBm
