AMS00x • Embedded Bluetooth Low Energy Solution

Pinout and Signal Descriptions, Section 5

ADS-MS00x-107R • Preliminary Data Sheet

Page | 9

©2014-2015 ACKme Networks. http://ack.me

September 14, 2015

Pin

Name

Primary Function

Alternate & Other Function(s)

11

GPIO_6

I/O

GPIO

12

GPIO_7

N/C

Reserved. Not available as digital I/O

13

GPIO_8

I/O

GPIO

SPI_MISO (Master)

14

GPIO_9

I/O

GPIO

SPI_CLK (Master)

15

I/O

GPIO

ADC, PWM

16

GPIO_11

I/O

GPIO

ADC, PWM

17

GPIO_12

I/O

GPIO

SPI_CS (Master), ADC

18

I/O

GPIO

ADC, PWM, XOSC32_OUT

19

GND

S

Ground

-

20

I/O

GPIO

ADC, PWM, XOSC32K_IN

21

VDD

S

VDD

-

22-27

GND

S

Ground

-

Notes:

1. I = Input, O = Output, S = Supply

2. The drive strength of standard GPIOs is 2mA, the drive strength of this GPIO is 16mA.

3. The FACTORY_RESET pin may be moved to a different GPIO, but it may not be de-assigned

4. Connected to SPI serial flash inside the module
