Unit：mm

http://www.ddknet.co.jp

27DS Series

2

◎ Specifications and/or dimensions in this catalog are subject to change without notice.

　Your checking the latest specifications with our drawings would be highly appreciated.

○Plug

○Right Angle Plug

○Bulkhead Jack

Part Number

Applicable

Cable

Finish

Assembly

Instruction Crimp Tool

Outer

Conductor

Center

Conductor

27DS-P-1.5-CF

1.5D-QEV

Ni

Au

1

CR-H-1101

1.5D-2V

27DS-P-196U-CF RG-196A/U

Ni

Au

1

CR-H-1101

16.3

Part Number

Applicable

Cable

Finish

Assembly

Instruction Crimp Tool

Outer

Conductor

Center

Conductor

27DS-LP-1.5-CF

1.5D-QEV

Ni

Au

2

CR-H-1101

1.5D-2V

27DS-LP-196U-CF RG-196A/U

Ni

Au

2

CR-H-1101

13.9

φ4

6.35

Part Number

Applicable

Cable

Finish

Assembly

Instruction Crimp Tool

Outer

Conductor

Center

Conductor

27DS-BJ-1.5-CF

1.5D-QEV

Ni

Au

1

CR-H-1101

1.5D-2V

(17)

11

1.2

Panel Mounting Hole

φ5.2

+0.1

0

+0.1

0

Panel Thickness : 3.0 Max.
