Industrial Layer-3 28-port managed Gigabit PoE Ethernet switch

with 24x10/100/1000Base-T(X) P.S.E. and 4x1G/10GBase-X, SFP+

socket, power supply included

RGPS-R9244GP+-P

▪

Supports Layer 3 routing, RIP and static routing function

▪

Support O-Ring (recovery time < 30ms over 250 units of connection) and

MSTP(RSTP/STP compatible) for Ethernet Redundancy

▪

O-Chain allow multiple redundant network rings

▪

function

▪

24 port P.S.E. fully compliant with IEEE802.3at standard, provide up to 30

Watts per port

▪

Support PoE scheduled configuration and PoE auto-ping check function

▪

Support hardware IEEE 1588v2 clock synchronization

▪

Support IPV6 new internet protocol version

▪

Support Modbus TCP protocol

▪

Support IEEE 802.3az Energy-Efficient Ethernet technology

▪

Provided HTTPS/SSH protocol to enhance network security

▪

Support SMTP client

▪

Support IP-based bandwidth management

▪

Support application-based QoS management

▪

Support Device Binding security function

▪

Support DOS/DDOS auto prevention

▪

IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic

▪

Support SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management

▪

Support ACL, TACACS+ and 802.1x User Authentication for security

▪

Supports 9.6K Bytes Jumbo Frame

▪

SFP socket support DDM function

▪

Multiple notification for warning of unexpected event

▪

Web-based ,Telnet, Console (CLI), and Windows utility (Open-Vision)

configuration

▪

Support LLDP Protocol

▪

19 inches rack mountable design

RGPS-R9244GP+-P is Layer-3 Gigabit managed redundant ring PoE Ethernet switch with 24x10/100/1000Base-T(X) IEEE802.3at P.S.E. ports and

4x1G/10GBase-X SFP+ ports. The switch support Ethernet Redundancy protocol, O-Ring (recovery time < 30ms over 250 units of connection) and MSTP (RSTP/

STP compatible) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. RGPS-

R9244GP+-P also support Power over Ethernet, a system to transmit electrical power up to 30 watts, along with data, to remote devices over standard twisted-

pair cable in an Ethernet network. Each RGPS-R9244GP+-P switch had 24x10/100/1000Base-T(X) P.S.E. (Power Sourcing Equipment) ports. P.S.E. is a device

(switch or hub for instance) that will provide power in a PoE connection. And RGPS-R9244GP+-P support wide operating temperature from -20

RGPS-R9244GP+-P can also be managed centralized and convenient by Open-Vision, as well as the Web-based interface, Telnet and console (CLI) configuration.

Therefore, the switch is one of the most reliable choice for highly-managed and Fiber PoE Ethernet application.

Introduction

Features

Full Gigabit

Industrial Ethernet Switch Rack-Mount Managed Gigabit PoE Ethernet Switch

v1.1a/ Apr, 2014

RGPS-R9244GP+-P

*NOTE: This function is available by request only
