Designed for Rugged Excellence

Dimensions

(Unit=mm)

Specifications

ORing Switch Model

RGPS-R92244GP+-P

Physical Ports

10/100/1000Base-T(X) with P.S.E. Ports in RJ45 Auto

MDI/MDIX

24

1G/10GBase-X with SFP+ port

4

Technology

Ethernet standards

IEEE 802.3 for 10Base-T

IEEE 802.3u for 100Base-TX and 100Base-FX

IEEE 802.3ab for 1000Base-T

IEEE 802.z for 1000Base-X

IEEE 802.3ae for 10Gigabit Ethernet

IEEE 802.3x for Flow control

IEEE 802.3ad for LACP (Link Aggregation Control Protocol )

IEEE 802.1p for COS (Class of Service)

IEEE 802.1Q for VLAN Tagging

IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol)

IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol)

IEEE 802.1x for Authentication

IEEE 802.1AB for LLDP (Link Layer Discovery Protocol)

IEEE 802.3at PoE specification (up to 30 Watts per port for P.S.E.)

-20 ~ 55

55 ~ 60

MAC table

8K

Priority queues

8

Processing

Store-and-Forward
