Designed for Rugged Excellence

Physical Characteristics

Enclosure

19 inches rack-mountable

Dimensions (W x D x H)

431 (W) x 342 (D) x 44 (H) mm (16.97 x 13.47 x 1.73 inch)

Weight (g)

6520 g

Environmental

Storage temperature

-40 to 85°C (-40 to 185°F)

Operating temperature

-20 to 60°C (-4 to 140°F)

Operating humidity

5% to 95% Non-condensing

Available

Model

Model Name

Description

RGPS-R9244GP+-P_US

Industrial Layer-3 28-port managed Gigabit PoE Ethernet switch with 24x10/100/1000Base-T(X) P.S.E. and

4x1G/10GBase-X, SFP+ socket, high watts power supply included, US power cord

RGPS-R9244GP+-P_EU

Industrial Layer-3 28-port managed Gigabit PoE Ethernet switch with 24x10/100/1000Base-T(X) P.S.E. and

4x1G/10GBase-X, SFP+ socket, high watts power supply included, EU power cord

RGPS-R9244GP+-P_UK

Industrial Layer-3 28-port managed Gigabit PoE Ethernet switch with 24x10/100/1000Base-T(X) P.S.E. and

4x1G/10GBase-X, SFP+ socket, high watts power supply included, UK power cord

RGPS-R9244GP+-P_JP

Industrial Layer-3 28-port managed Gigabit PoE Ethernet switch with 24x10/100/1000Base-T(X) P.S.E. and

4x1G/10GBase-X, SFP+ socket, high watts power supply included, JP power cord

Packing List

‧

RGPS-R9244GP+-P

‧

Rack-Mount Kit

‧

Power Cable

‧

ORing Tool CD

‧

Quick Installation Guide

‧

Console Cable

‧

Open-Vision M500, Powerful Network Management Windows Utility Suite, 500 IP devices

‧

SFP1G series, 1Gbps SFP optical transceiver

‧

SFP10G series : 10GMbps SFP optical transceiver

RGPS-R9 AA B CCC- P

Ordering Information

Code Definition 10/100/1000Base-T(X) P.S.E.

Port Number

Additional Port Number

Additional Port Type

Option

- 24: 24 ports

- 4: 4 ports

-GP+: 1G / 10GBase-X, SFP+ socket

Regulatory Approvals

EMI

FCC Part 15, CISPR (EN55022) class A

EMS

EN61000-4-2 (ESD)

EN61000-4-3 (RS),

EN61000-4-4 (EFT),

EN61000-4-5 (Surge),

EN61000-4-6 (CS),

EN61000-4-8,

EN61000-4-11

Shock

IEC60068-2-27

Free fall

IEC60068-2-32

Vibration

IEC60068-2-6

Warranty

5 years

Industrial Ethernet Switch C1D2 DIN-Rail Unmanaged Ethernet Switch

v1.1a/ Apr, 2014
