13 / 66 page

H7CC-A

Connection Sockets

Front Connecting Socket

Note: Round crimp terminals cannot be used on Finger-safe Sockets. Use forked crimp terminals.

Back-connecting Sockets

Note: A Y92A-48G Terminal Cover can be used with the Socket to create a finger-safe construction.

Model

Dimensions

Terminal arrangement

and internal connections

Mounting hole

dimensions

P2CF-11

(Top View)

Note: The Socket can also

be mounted to DIN

track.

P2CF-11-E

(Finger-safe Type)

P2CF-08

Note: The Socket can also

be mounted to DIN

track.

P2CF-08-E

(Finger-safe Type)

Model

Dimensions

Terminal arrangement

and internal connections

P3GA-11

(Bottom View)

P3GA-08

（BOTTOM VIEW）

70 max.

50 max.

Two, 4.5-dia. holes

Eleven, M3.5

× 7.5

sems screws

7.8

31.2 max.

4.5

35.4

40±0.2

Two, M4 or 4.5-dia. holes

P2CF-11-E

10A250VAC

RESISTIVE

40±0.2

7.8

4.5

35.4

1.2

70 max.

50 max.

Two, 4.5-dia. holes

Eleven, M3.5

× 7.5

set screws

31.2 max.

70 max.

7.8

20.3 max.

4.5

50 max.

35.4

Eight, M3.5

× 7.5

Two, 4.5-dia.

holes

(Top View)

40±0.2

Two, M4 or 4.5-dia. holes

P2CF-08-E

10A250VAC

RESISTIVE

7.8

21.5 max.

20.3

4.5

35.4

1.3

40±0.2

70 max.

50 max.

Eight, M3.5

× 7.5

Two, 4.5-dia.

holes

27 dia.

4.5

16.3

6.2

25.6

4.9

27 dia.

5 6

8 7
