Click the variable in the global variable table to show a list of the

locations where the variable is used in the Cross Reference Tab Page.

Click the location to access the object where the variables is used.

Cross references

The same GUI for the cross reference function as the NJ/NX/NY Controller can be used.

When a variable is clicked in the global variable table, a list of the locations where the variable is used is displayed

in the Cross Reference Tab Page.

By clicking the location, you can access the object, subroutine, or ladder program where the variable is used

across the entire project. This makes screen design and debugging quicker and easier.

1) Enter a text string

to search/replace

2) Start to

search/replace

Display the object

to search/replace

3) The results are

displayed

Search and Replace

You can search and replace text

strings in all subroutines (Visual

Basic), objects, and variables within

a project.

It is quick and easy to edit and

debug variable names and switch

labels.
