SCREEN MASTER® 5-MM OVAL LEDs C566C-RFF/RFE/AFF/AFE

© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered

trademarks of Cree LED.

CLD-CT1241

REV 5

3

INTENSITY BIN LIMIT

Red (20 mA) - C566C-RFF/RFE

Amber (20 mA) - C566C-AFF/AFE

Bin Code

Min.(mcd)

Max.(mcd)

Bin Code

Min.(mcd)

Max.(mcd)

U0

1520

2130

U0

1520

2130

V0

2130

3000

V0

2130

3000

W0

3000

4180

W0

3000

4180

*

Tolerance of measurement of luminous intensity is ±15%

COLOR BIN LIMIT

Red (20 mA) - C566C-RFF/RFE

Amber (20 mA) - C566C-AFF/AFE

Bin Code

Min.(nm)

Max.(nm)

Bin Code

Min.(nm)

Max.(nm)

RB

619

624

A2

584

587

A3

587

590

A4

590

593

A5

593

596

*

Tolerance of measurement of dominant wavelength is ±1 nm.
