SCREEN MASTER® 5-MM OVAL LEDs C566C-RFF/RFE/AFF/AFE

© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered

trademarks of Cree LED.

CLD-CT1241

REV 5

4

ORDER CODE TABLE

C566C-RFF/RFE

Color

Kit Number

Luminous Intensity (mcd)

Dominant Wavelength

Package

Standoff

Min.

Max.

Color Bin

Min. (nm)

Color Bin

Max. (nm)

Red

C566C-RFF-CU0W0BB1

1520

4180

RB

619

RB

624

Bulk

Yes

Red

C566C-RFF-CU0V0BB1

1520

3000

RB

619

RB

624

Bulk

Yes

Red

C566C-RFF-CV0W0BB1

2130

4180

RB

619

RB

624

Bulk

Yes

Red

C566C-RFE-CU0W0BB1

1520

4180

RB

619

RB

624

Bulk

No

Red

C566C-RFE-CU0V0BB1

1520

3000

RB

619

RB

624

Bulk

No

Red

C566C-RFE-CV0W0BB1

2130

4180

RB

619

RB

624

Bulk

No

Red

C566C-RFF-CU0W0BB2

1520

4180

RB

619

RB

624

Ammo

Yes

Red

C566C-RFF-CU0V0BB2

1520

3000

RB

619

RB

624

Ammo

Yes

Red

C566C-RFF-CV0W0BB2

2130

4180

RB

619

RB

624

Ammo

Yes

Red

C566C-RFE-CU0W0BB2

1520

4180

RB

619

RB

624

Ammo

No

Red

C566C-RFE-CU0V0BB2

1520

3000

RB

619

RB

624

Ammo

No

Red

C566C-RFE-CV0W0BB2

2130

4180

RB

619

RB

624

Ammo

No

C566C-AFF/AFE

Color

Kit Number

Luminous Intensity (mcd)

Dominant Wavelength

Package

Standoff

Min.

Max.

Color Bin

Min. (nm)

Color Bin

Max. (nm)

Amber

C566C-AFF-CU0W0251

1520

4180

A2

584

A5

596

Bulk

Yes

Amber

C566C-AFF-CU0V0341

1520

3000

A3

587

A4

593

Bulk

Yes

Amber

C566C-AFF-CV0W0341

2130

4180

A3

587

A4

593

Bulk

Yes

Amber

C566C-AFE-CU0W0251

1520

4180

A2

584

A5

596

Bulk

No

Amber

C566C-AFE-CU0V0341

1520

3000

A3

587

A4

593

Bulk

No

Amber

C566C-AFE-CV0W0341

2130

4180

A3

587

A4

593

Bulk

No

Amber

C566C-AFF-CU0W0252

1520

4180

A2

584

A5

596

Ammo

Yes

Amber

C566C-AFF-CU0V0342

1520

3000

A3

587

A4

593

Ammo

Yes

Amber

C566C-AFF-CV0W0342

2130

4180

A3

587

A4

593

Ammo

Yes

Amber

C566C-AFE-CU0W0252

1520

4180

A2

584

A5

596

Ammo

No

Amber

C566C-AFE-CU0V0342

1520

3000

A3

587

A4

593

Ammo

No

Amber

C566C-AFE-CV0W0342

2130

4180

A3

587

A4

593

Ammo

No

Notes:

•

The above kit numbers represent order codes that include multiple intensity-bin and color-bin codes. Only one intensity-bin code and one color-bin

code will be shipped on each reel. single intensity-bin, single color-bin codes will not be orderable.

•

Please refer to the

HB LED Lamp Reliability Test Standards document for reliability test conditions.

•

Please refer to the

HB LED Lamp Soldering & Handling document for information about how to use this LED product safely.
