SCREEN MASTER® 5-MM OVAL LEDs C566C-RFF/RFE/AFF/AFE

© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered

trademarks of Cree LED.

CLD-CT1241

REV 5

2

ABSOLUTE MAXIMUM RATINGS (T

A = 25°C)

Items

Symbol

Absolute Maximum Rating

Unit

Red and Amber

Forward Current

I

F

50 Note1

mA

Peak Forward Current Note2

I

FP

200

mA

Reverse Voltage

V

R

5

V

Power Dissipation

P

D

130

mW

Operation Temperature

T

opr

-40 ~ +95

°C

Storage Temperature

T

stg

-40 ~ +100

°C

Lead Soldering Temperature

T

sol

Max. 260°C for 3 sec. max.

(3 mm from the base of the epoxy bulb)

Electrostatic Discharge

Classification (MIL-STD-883E)

ESD

Class 2

Note:

1.

For long term performance the drive currents between 10mA and 30mA are recommended. Please contact Cree LED sales representative for more

information on recommended drive conditions.

2.

Pulse width ≤0.1 msec, duty ≤1/10.

TYPICAL ELECTRICAL & OPTICAL CHARACTERISTICS (T

A = 25°C)

Characteristics

Color

Symbol

Condition

Unit

Minimum

Typical

Maximum

Forward Voltage

Red/Amber

V

F

I

F = 20 mA

V

2.1

2.6

Reverse Current

Red/Amber

I

R

V

R = 5 V

μA

100

Dominant Wavelength

Red

λ

D

I

F = 20 mA

nm

619

621

624

Amber

λ

D

I

F = 20 mA

nm

584

591

596

Luminous Intensity

Red

I

V

I

F = 20 mA

mcd

1520

2200

Amber

I

V

I

F = 20 mA

mcd

1520

2200

*

Continuous reverse voltage can cause LED damage.
