PRODUCT FAMILY DATA SHEET

Cree LED / 4001 E. Hwy. 54, Suite 2000 / Durham, NC 27709 USA / +1.919.313.5330 / www.cree-led.com

© 2021-2024 Cree LED. The information in this document is subject to change without notice. Cree®, the Cree logo and the Cree LED logo are registered

trademarks of Cree LED.

CLD-CT1241

REV 5

1

Screen Master® 5-mm Oval LEDs: C566C-RFF/RFE/AFF/AFE

PRODUCT DESCRIPTION

These oval LEDs are specifically designed

for full-colorvideoscreens,digitalbillboards

and passenger-information signs. The oval-

shaped radiation pattern and high luminous

intensity ensure that these devices are

excellent for bright sunlight or low power

consumption outdoor applications.

These lamps are made with an advanced

optical-grade epoxy that offers superior

high-temperature

and

high-moisture-

resistance performance in outdoor signal

and sign applications.The encapsulation

resin contains anti-UV material in order to

reduce the effects of long-term exposure to

direct sunlight.

FEATURES

• Size (mm): 5

• Color and Typical Dominant

Wavelength:

Red (621nm)

Amber(591nm)

• Luminous Intensity (mcd)

C566C-RFF/RFE: (1520-4180)

C566C-AFF/AFE: (1520-4180)

• Viewing angle:

70 X 35 degree

• Lead - Free

• RoHS Compliant

APPLICATIONS

• Electronic Signs & Signals (ESS)

• Full Color Video Screen

• Digital Billboards

• Motorway Signs

• Variable Message Sign (VMS)

• Advertising Signs

• Petrol Signs
