AD8532ARM-R2 数据表(PDF) 7 Page - Analog Devices

部件名 AD8532ARM-R2
功能描述  Low Cost, 250 mA Output, Single-Supply Amplifiers
PDF  20 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
制造商  AD [Analog Devices]
网页  http://www.analog.com
标志 AD - Analog Devices

AD8532ARM-R2 数据表(HTML) 7 Page - Analog Devices

Back Button AD8532ARM-R2 Datasheet HTML 3Page - Analog Devices AD8532ARM-R2 Datasheet HTML 4Page - Analog Devices AD8532ARM-R2 Datasheet HTML 5Page - Analog Devices AD8532ARM-R2 Datasheet HTML 6Page - Analog Devices AD8532ARM-R2 Datasheet HTML 7Page - Analog Devices AD8532ARM-R2 Datasheet HTML 8Page - Analog Devices AD8532ARM-R2 Datasheet HTML 9Page - Analog Devices AD8532ARM-R2 Datasheet HTML 10Page - Analog Devices AD8532ARM-R2 Datasheet HTML 11Page - Analog Devices Next Button
Zoom Inzoom in Zoom Outzoom out
 7 / 20 page
background image
AD8531/AD8532/AD8534
Rev. F | Page 7 of 20
SOURCE
SINK
LOAD CURRENT (mA)
1000
100
10
1
0.01
0.1
0.001
0.01
0.1
1
10
100
VS = 2.7V
TA = 25°C
Figure 12. Output Voltage to Supply Rail vs. Load Current
LOAD CURRENT (mA)
1000
100
10
1
0.1
0.01
0.001
0.01
0.1
1
10
100
VS = 5V
TA = 25°C
SINK
SOURCE
Figure 13. Output Voltage to Supply Rail vs. Load Current
FREQUENCY (Hz)
80
60
40
20
0
45
90
135
180
1k
10k
100k
1M
10M
100M
VS = 2.7V
RL = NO LOAD
TA = 25°C
Figure 14. Open-Loop Gain and Phase Shift vs. Frequency
FREQUENCY (Hz)
80
60
40
20
0
45
90
135
180
1k
10k
100k
1M
10M
100M
VS = 5V
RL = NO LOAD
TA = 25°C
Figure 15. Open-Loop Gain and Phase Shift vs. Frequency
FREQUENCY (Hz)
5
4
3
1
2
0
1k
10k
100k
1M
10M
VS = 2.7V
TA = 25°C
RL = 2kΩ
VIN = 2.5V p-p
Figure 16. Closed-Loop Output Swing vs. Frequency
FREQUENCY (Hz)
5
4
3
1
2
0
1k
10k
100k
1M
10M
VS = 5V
TA = 25°C
RL = 2kΩ
VIN = 4.9V p-p
Figure 17. Closed-Loop Output Swing vs. Frequency
