Low-Power, Multifunction, Polyphase AFE

with Harmonics and Tamper Detect

______________________________________________________________________________________

Checksum (CHKSUM) (0x066)

This register contains the calculated 16-bit arithmetic checksum over critical configuration and calibration registers.

It is updated on every DSP cycle. In use, the administrative processor records the value in the CHKSUM register and

then checks it periodically to verify that no configuration or calibration registers have changed. The MAXQ3183 sets

the CHSCH bit when this register’s value changes.

The registers included in the checksum calculation include the following:

Bit:

Name:

Checksum High Byte

Reset:

Bit:

Name:

Checksum Low Byte

Reset:

SYS_KHZ

THR2

R_ADCRATE

A.I_GAIN

B.I_GAIN

C.I_GAIN

VOLT_CC

REJ_NS

R_ADCACQ

A.V_GAIN

B.V_GAIN

C.V_GAIN

AMP_CC

AVG_NS

R_SPICF

A.E_GAIN

B.E_GAIN

C.E_GAIN

PWR_CC

AVG_C

ISUMLVL

A.EF_GAIN

B.EF_GAIN

C.EF_GAIN

ENR_CC

HPF_C

COM_TIMO

A.OFFS_HI

B.OFFS_HI

C.OFFS_HI

CYCNT

B0FUND

ACC_TIMO

A.GAIN_LO

B.GAIN_LO

C.GAIN_LO

PLSCFG1

OCLVL

I1THR

A.OFFS_LO

B.OFFS_LO

C.OFFS_LO

PLSCFG2

OVLVL

I2THR

A.PA0

B.PA0

C.PA0

PLS1_WD

UVLVL

ZC_LPF

A.PA1

B.PA1

C.PA1

THR1

NOLOAD

N.GAIN

A.PA2

B.PA2

C.PA2

PLS2_WD

R_ACFG

TEMP_CC
