Low-Power, Multifunction, Polyphase AFE

with Harmonics and Tamper Detect

______________________________________________________________________________________

Interrupt Mask Register (IRQ_MASK) (0x006)

BIT

NAME

FUNCTION

EDSPOR

When set, the DSPOR flag causes the IRQ pin to become active.

EDSPRDY

When set, the DSPRDY flag causes the IRQ pin to become active.

EDCHR

When set, the DCHR flag causes the IRQ pin to become active.

EDCHA

When set, the DCHA flag causes the IRQ pin to become active.

ENOZX

When set, the NOZX flag causes the IRQ pin to become active.

EUV

When set, the UV flag causes the IRQ pin to become active.

EOV

When set, the OV flag causes the IRQ pin to become active.

EOC

When set, the OC flag causes the IRQ pin to become active.

7:4

—

Reserved.

EISUM

When set, the ISUMOVF flag causes the IRQ pin to become active.

EEOVF

When set, the EOVF flag causes the IRQ pin to become active.

ECHSCH

When set, the CHSCH flag enables the IRQ pin to become active.

EPWRF

When set, the PWRF flag causes the IRQ pin to become active.

Bit:

Name:

EDSPOR

EDSPRDY

EDCHR

EDCHA

ENOZX

EUV

EOV

EOC

Reset:

Bit:

Name:

—

EISUM

EEOVF

ECHSCH

EPWRF

Reset:
