Low-Power, Multifunction, Polyphase AFE

with Harmonics and Tamper Detect

______________________________________________________________________________________

Energy Units Conversion Coefficient (ENR_CC) (0x01A)

This register contains the value by which the raw accumulated energy value in each phase is multiplied before being

presented to the virtual energy registers. The table below lists the raw energy accumulators and the corresponding

virtual registers.

Bit:

Name:

Energy Units Conversion Coefficient High Byte

Reset:

0x00

Bit:

Name:

Energy Units Conversion Coefficient Low Byte

Reset:

0x01

DESCRIPTION

RAW

VIRTUAL

Real energy, phase A, positive direction

A.EAPOS

Real energy, phase A, reverse direction

A.EANEG

ENRP.A*

Real energy, phase B, positive direction

B.EAPOS

Real energy, phase B, reverse direction

B.EANEG

ENRP.B*

Real energy, phase C, positive direction

C.EAPOS

Real energy, phase C, reverse direction

C.EANEG

ENRP.C*

Real energy, total

—

ENRP.T

Reactive energy, phase A, positive direction

A.ERPOS

Reactive energy, phase A, reverse direction

A.ERNEG

ENRQ.A*

Reactive energy, phase B, positive direction

B.ERPOS

Reactive energy, phase B, reverse direction

B.ERNEG

ENRQ.B*

Reactive energy, phase C, positive direction

C.ERPOS

Reactive energy, phase C, reverse direction

C.ERNEG

ENRQ.C*

Reactive energy, total

—

ENRQ.T

Apparent energy, phase A

A.ES

ENRS.A

Apparent energy, phase B

B.ES

ENRS.B

Apparent energy, phase C

C.ES

ENRS.C

Apparent energy, total

—

ENRS.T

Real energy, phase A, positive direction, fundamental only

A.EAFPOS

Real energy, phase A, reverse direction, fundamental only

A.EAFNEG

ENRPF.A*

Real energy, phase B, positive direction, fundamental only

B.EAFPOS

Real energy, phase B, reverse direction, fundamental only

B.EAFNEG

ENRPF.B*

Real energy, phase C, positive direction, fundamental only

C.EAFPOS

Real energy, phase C, reverse direction, fundamental only

C.EAFNEG

ENRPF.C*

Real energy, total, fundamental only

—

ENRPF.T

Reactive energy, phase A, positive direction, fundamental only

A.ERFPOS

Reactive energy, phase A, reverse direction, fundamental only

A.ERFNEG

ENRQF.A*

Reactive energy, phase B, positive direction, fundamental only

B.ERFPOS

Reactive energy, phase B, reverse direction, fundamental only

B.ERFNEG

ENRQF.B*

These registers represent the algebraic sum of the positive and reverse energy in the two “raw” registers noted. Thus, the energy

returned in these virtual registers represents the net energy.
