Document Number: 002-05615 Rev. *D
Page
105 of 112
MB9B410R Series
14.
Package Dimensions
Package Type
Package Code
LQFP 100
LQI100
NOTES :
1. ALL DIMENSIONS ARE IN MILLIMETERS.
2. DATUM PLANE H IS LOCATED AT THE BOTTOM OF THE MOLD PARTING
LINE COINCIDENT WITH WHERE THE LEAD EXITS THE BODY.
3. DATUMS A-B AND D TO BE DETERMINED AT DATUM PLANE H.
4. TO BE DETERMINED AT SEATING PLANE C.
5. DIMENSIONS D1 AND E1 DO NOT INCLUDE MOLD PROTRUSION.
ALLOWABLE PROTRUSION IS 0.25mm PRE SIDE.
DIMENSIONS D1 AND E1 INCLUDE MOLD MISMATCH AND ARE DETERMINED
AT DATUM PLANE H.
6. DETAILS OF PIN 1 IDENTIFIER ARE OPTIONAL BUT MUST BE LOCATED
WITHIN THE ZONE INDICATED.
7. REGARDLESS OF THE RELATIVE SIZE OF THE UPPER AND LOWER BODY
SECTIONS. DIMENSIONS D1 AND E1 ARE DETERMINED AT THE LARGEST
FEATURE OF THE BODY EXCLUSIVE OF MOLD FLASH AND GATE BURRS.
BUT INCLUDING ANY MISMATCH BETWEEN THE UPPER AND LOWER
SECTIONS OF THE MOLDER BODY.
8. DIMENSION b DOES NOT INCLUDE DAMBAR PROTRUSION. THE DAMBAR
PROTRUSION (S) SHALL NOT CAUSE THE LEAD WIDTH TO EXCEED b
MAXIMUM BY MORE THAN 0.08mm. DAMBAR CANNOT BE LOCATED ON
THE LOWER RADIUS OR THE LEAD FOOT.
9. THESE DIMENSIONS APPLY TO THE FLAT SECTION OF THE LEAD
BETWEEN 0.10mm AND 0.25mm FROM THE LEAD TIP.
10. A1 IS DEFINED AS THE DISTANCE FROM THE SEATING PLANE TO
THE LOWEST POINT OF THE PACKAGE BODY.
DIMENSIONS
SYMBOL
MIN.
NOM. MAX.
A
1.70
A1
0.05
0.15
b
0.15
0.27
c
0.09
0.20
D
16.00 BSC
D1
14.00 BSC
e
0.50 BSC
E
E1
L
0.45
0.60
0.75
L1
0.30
0.50
0.70
16.00 BSC
14.00 BSC
A
A1
0.25
0.0 8 C
1
100
D1
D
E1 E
e
4
4
0.0 8
C A-B
D
7
5
SEAT ING
PLA NE
0.2 0 C A-B D
0.1 0 C A-B D
b
SECTION A-A'
c
9
A
A'
5 7
5
7
3
3
6
8
10
2
2
L1
L
b
D1
D
E1 E
4
4
5 7
5
7
25
26
50
51
75
76
SIDE VIEW
TOP VIEW
BOTTOM VIEW
DETAIL A
1
25
26
50
5
7
1
5
100
76
PACKAGE OUTLINE, 100 LEAD LQFP
14.0X14.0X1.7 MM LQI100 REV*A
002-11500 *A
