7 / 21 page

sFerrules

qFor APC

(1)No gap design.

(2)The entrance angle of the fiber has been set at 60

° for easy fiber insertion.

qFor PC, AdPC and UPC

Minimal gap:(0.1mm max.)

60° fiber entrance angle

1.5

1.8

7.95+0.05

16.15

8.095 +0.05

1.8

sReceptacles

Note: Designed for power meter sensors

15.2

13.4

2-Ø2.3

12.2

CL No.

704-0070-9-10

704-0200-2-10

704-0071-1-10

Part Number

HSC-F321-A125(10)

HSC-F321-A1255(10)

HSC-F321-A126(10)

A dimension

0.125

0.1255

0.126

Applicable Fiber cable

SM,MM

CL No.

704-0022-6-05

704-0023-9-05

Part Number

HSC-R1-B(05)

HSC-R2-B(05)

Remarks

For MM

For SM

CL No.

704-3101-7

704-3102-0

704-3103-2

Part Number

HSC-F391-A125

HSC-F391-A126

HSC-F391-A127

A dimension

0.125

0.126

0.127

Applicable Fiber cable
