HSC-R2-B datasheet(20/21 Pages) HIROSE

部件名	HSC-R2-B

功能描述	SC Type Fiber Optic Connectors

PDF	21 Pages

Scroll/Zoom	100%

制造商	HIROSE [Hirose Electric]

网页	http://www.hirose-connectors.com

标志

20 / 21 page

16.2

3 9.4

7.8

qDuplex F Type / Unshrouded

BPanel cut-out

25.7

+0.5

30.7±0.1

2-M2∞0.4 or 2-Ø2.4

+0.2

q8-Position / Shrouded

sSimplified Receptacles to SC2

Ø2.3

12.4

24.3

10.7 3

8 S R

12.7

+0.5

2-M2∞0.4

or 2-Ø2.4

+0.2

q4-position / Shrouded

JAPAN

4SR

10.73

24.3

12.4

2-M2∞0.4

or 2-Ø2.4

+0.2

12.7

+0.5

Part Number

CL No.

Split sleeve

Color

HSCF-2SR-2(P)(51)

704-0295-9-51

Copper alloy

HSCF-2SR-D2(P)(02)

704-0296-1-02

Zirconia

Blue

HSCF-2SR-2(P)(03)

704-0295-9-03

None

Part Number

CL No.

Split sleeve

Color

HSC2-4SR-1(51)

704-0311-3-51

Copper alloy

HSC2-4SR-D1(01)

704-0312-6-01

Zirconia

Blue

HSC2-4SR-1(03)

704-0311-3-03

None

Part Number

CL No.

Split sleeve

Color

HSC2-8SR-1(51)

704-0266-0-51

Copper alloy

HSC2-8SR-D1(01)

704-0270-8-01

Zirconia

Blue

HSC2-8SR-1(03)

704-0266-0-03

None
