ø30 Series Accessories and Replacement Parts ø30

Accessories

Shape

Material

Part No.

Ordering

No.

Package

Quantity

Dimensions (mm)

Button Cover for

Extended Pushbuttons

Rubber (nitryl)

Color

Part No.

–

M30P1.5

ø38

ø28

•Metallicbezelscovered

witharubberbootto

enhancewaterproof

characteristics.

•Buttonisnotincluded.

Applicabletoextended

pushbuttonsonly.

Black

OC-11B

Green

OC-11R

Red

OC-11G

Yellow

OC-11Y

Button

Clear Boot

For flush

pushbuttons

Rubber

(EPDM)

OC-121

•Usedtocoverand

protectpushbuttons

whereunitsaresubject

towatersplash.Not

suitableforoutdooruse

orwheretheunitsare

subjecttooilsplash.

OC-121

OC-122

For extended

pushbuttons

OC-122

Dust-proof Rubber Cover

for Jumbo Mushrooms

Rubber

(nitryl)

black

OC-4GN

Panel Thickness

1.2 to 5.5

•UsedforABN4G

pushbuttons.

Padlock Cover

Polyarylate

(gasket: nitryl

rubber)

OL-KL1

•Used to protect pushbuttons, illuminated push-

buttons, and selector switches (knob operator).

Metal Protector

Metal

(zinc-plated)

OL-C

•Used to protect flush pushbuttons from

inadvertent operation.

•Can be easily attached using the locking ring.

ø30.5

11.5

1.6

42.5

Locking Attachmentt

Metal

(zinc-plated)

OL-H

•Used to lock an extended pushbutton in the

depressed position.

•Can be easily attached using the locking ring.

ø6 hole

Locking Plate

Mounting Plate

Waterproof Rubber

Gasket 0.5t

Key Hole ø8

ø50

ø30.2

29.5

Panel Thickness

0.8 to 3.2

82.5

ø30

(14/03/18)
