ø30 ø30 Series Accessories and Replacement Parts

Maintenance Parts

Shape

Specification

Part No.

Ordering No.

Package

Quantity

Remarks

Metallic Bezel

Metal

(zinc diecast: chrome-

plated)

OG-11

OG-11PN02

• Cannot be used with pin lock,

selector pushbuttons, and mono-

lever units.

Plastic Bezel

Plastic

(polycarbonate)

OGP-11∗

OGP-11∗PN02

Specify a color code in place of

∗.

B (black), G (green), R (red), W

(white),

Y (yellow)

• Cannot be used with pin lock,

selector pushbuttons, and mono-

lever units.

Clear Plastic Bezel for Flush

Pushbuttons

Clear Plastic

(acrylic)

OGP-13

OGP-13PN02

• Clear plastic bezel and full

shroud.

• OGP-1411 cannot be used with

LED illumination units and diecast

units.

Clear Plastic Bezel for

Extended Pushbuttons

OGP-14

OGP-14PN02

Clear Plastic Bezel for

Illuminated Pushbuttons

OGP-1411

Metal Bezel for Illuminated

Pushbuttons

Metal

(zinc diecast)

OL-11

OL-11PN05

Clear Button Cover

Clear Plastic

(polycarbonate)

ABN1B-C

ABN1B-CPN05

• Used on flush and extended

pushbuttons to indicate a mark or

a symbol engraved on the mark-

ing plate. The clear button cover

holds the marking plate. The ø30

series marking chip can only be

used on the ABN1 and AON1.

• Specify a color code in place of

∗.

B (black), G (green), R (red), W

(white), Y (yellow)

Marking Plate

Plastic

(polyacetal)

TN-0∗

TN-0∗PN10

(14/03/18)
